Description
| Specification | Details | ||
| External Dimensions | 177mm × 110mm × 103mm | Reduction Ratio | 1:50 |
| Packaging Box Dimensions | 385mm × 358mm × 175mm | Line Release Speed | 10m/min |
| Device Net Weight | 1.1kg (including battery) | Line Length for Deployment | 30M |
| Installation Method | Quick Release | Control Method | Independent Remote Control |
| Power Supply Method | Powered by the Aircraft Body | Signal Mode | PWM Signal |
| Operating Voltage | 24V | Control Distance | 800m (unobstructed) |
| Motor Type | Brushed DC Motor | Expansion Channel | Supports M600 expansion channel functionality |
| Motor Power | 22W | Maximum Load Capacity | 5KG |
| Motor Speed | 6000 rpm | Output Speed | 120 rpm |
